GMKtec NucBox G5S Mini PC – Intel Celeron Processor N5095, 4 Cores, 4 Threads, 2.0GHz Base Frequency, Up to 2.9GHz Burst Frequency, 4MB Intel Smart Cache, 10nm Process Technology, 10W TDP, 8GB LPDDR4 4800MT/s Non-Upgradable Memory, 256GB M.2 2242 SATA 3.0 SSD, Expandable Up to 8TB, Dual HDMI 2.0 Output, Support Dual 4K at 60Hz, WiFi 6 and Bluetooth 5.2 Connectivity, Windows 11 Pro, Retail Box, 1 Year Warranty.
Product Overview
The GMKtec NucBox G5S is an ultra‑compact mini PC powered by an Intel Celeron N5095 (4C/4T, up to 2.9GHz) for efficient everyday computing, web tasks, and light office work. It comes with 8GB LPDDR4 (non‑upgradable) and a 256GB M.2 2242 SATA SSD, expandable via microSD (up to 128GB) and storage upgrades up to 8TB. Dual HDMI 2.0 outputs support dual 4K@60Hz displays, with Wi‑Fi 6, Bluetooth 5.2, Gigabit LAN, multiple USB‑A ports, USB‑C power input, and Windows 11 Pro preinstalled.
Specifications
Product Code: G-G5S
•Description: GMKtec NucBox G5S Mini PC
•Processor (CPU): Intel Celeron Processor N5095
•Cores and Threads: 4 Cores / 4 Threads
•Base Frequency: 2.0GHz
•Burst Frequency: Up to 2.9GHz
•Cache: 4MB Intel Smart Cache
•Process Technology: 10nm
•TDP: 10W
Cooling System
•Copper Heat Pipe Cooling
•Single Cooling Fan
•Efficient 10W Low-Power Thermal Design
•GPU: Intel UHD Graphics
•Base Frequency: 450MHz
•Burst Frequency: Up to 750MHz
•Supports 4K Video Output
•Memory(RAM): 8GB Onboard Memory LPDDR4 4800MT/s Non-Upgradable
•Storage(ROM): 256GB M.2 2242 SATA 3.0 SSD
•Supports PCIe Gen3 ×2 NVMe & SATA SSD
•Expandable up to 8TB
•Display Output: Dual HDMI 2.0 Output
•Supports Dual 4K @ 60Hz Displays
•Wireless Connectivity: WiFi 6 (802.11ax/ac/a/b/g/n)
•2.4GHz + 5GHz Dual Band
•Maximum Speed: Up to 600Mbps
•Bluetooth 5.2
Power
•Built-in CMOS Battery
•USB Type-C Power Input
•12V / 3A Adapter
Front I/O
•1 × Power Button with Blue LED Indicator
•2 × USB-A 3.2 Gen1 (5Gbps)
Rear I/O
•2 × HDMI 2.0 (4K@60Hz)
•1 × USB-A 3.2 Gen1 (5Gbps)
•1 × USB-C Power Input
•1 × 3.5mm Audio Combo Jack
•1 × Gigabit RJ45 LAN (RTL8111H)
Expansion
•Micro SD Card Slot
•Supports up to 128GB SD Card
•VESA Mount Compatible
•Security Lock Slot
•Operating System: Windows 11 Pro
Power Management
•Auto Power On Supported
•BIOS Setting Available
•Dimensions: 72 × 72 × 44.5 mm
•Weight: Approx. 206g
